Enerpac RCS101 Low Height Hydraulic Cylinder 10 Ton, 38 mm Stroke
Estimated lead time:1 to 2 days delivery
Please call us if you need this item sooner
& COLLECT
delivery
DELIVERY
(Call us)
Seen this product cheaper elsewhere?
We will always try to offer this product at the best price. We will do our best to not just match it but to beat it.
Price match
promise
Enerpac RCS101 Low Height Hydraulic Cylinder 10 Ton, 38 mm Stroke
Brand:
Description
Enerpac RCS101 Low Height Hydraulic Cylinder 10 Ton, 38 mm Stroke provides superior durability, performance longevity, safety, and quality in a compact and convenient footprint giving a perfect choice where space is limited or constrained.
£394.99 ex VAT
£473.99 inc VAT
Add to cart
Add to quoteRelated products
Enerpac RC51 General Purpose Hydraulic Cylinder 5 Ton, 25 mm Stroke
RC51
Enerpac RC51 General Purpose Hydraulic Cylinder 5 Ton, 25 mm Stroke single-acting hydraulic cylinder that is suitable for a wide range of applications; lifting, pushing, or pressing of equipment. RC-Series Hydraulic Cylinders include a hybrid spring-return system for fast retraction and enhanced productivity.
£349.99 ex VAT
£419.99 inc VAT
Enerpac HC7206 High Pressure Hydraulic Hose x 1.8m
HC7206
The Enerpac HC7206 High-Pressure Hydraulic Hose x 1.8m long is available for next-day delivery from the ULS Lifting online store. Used to connect Cylinders to Pumps. Manufactured from thermo-plastic hoses for demanding applications. The HC7206 High-Pressure hose has an operating pressure of 700 Bar.
£123.99 ex VAT
£148.79 inc VAT
Enerpac P39 Single Speed Hydraulic Hand Pump
P39
The Enerpac P39 Single Speed Hydraulic Hand Pump belongs to the Ultima Steel Hand Pumps series that are durable, portable, and highly efficient. Each model in the series features an all-steel construction ideal long-lasting performance.
£399.99 ex VAT
£479.99 inc VAT
Enerpac HC7206C High Pressure Hydraulic Hose x 1.8m
HC7206C
The Enerpac HC7206C High-Pressure Hydraulic Hose x 1.8m long is available for next-day delivery from the ULS Lifting online store. Used to connect Cylinders to Pumps. Manufactured from thermo-plastic hoses for demanding applications. The HC7206C High-Pressure hose has an operating pressure of 700 Bar.
£154.99 ex VAT
£185.99 inc VAT
Enerpac RSM100 Low Height Hydraulic Cylinder 10 Ton, 11 mm Stroke
RSM100
Enerpac RSM100 Low Height Hydraulic Cylinder 10 Ton, 11 mm Stroke provides superior durability, safety, and quality in a compact and convenient format. The RSM-Series Low Profile Hydraulic Cylinders are the perfect choice for general lifting and production applications where space is limited.
£384.99 ex VAT
£461.99 inc VAT
Enerpac RCS101 Low Height Hydraulic Cylinder 10 Ton, 38 mm Stroke provides superior durability, performance longevity, safety, and quality in a compact and convenient footprint giving a perfect choice for general lifting and production applications where space is limited or constrained. A low collapsed height, short stroke, and solid construction enable safety and stability in both vertical and horizontal orientations.
Why use the Enerpac RSC-Series Low Profile Hydraulic Cylinders? - Many low-profile hydraulic cylinders rely on the weight of the load to retract the plunger. RCS cylinders are different and include a powerful return spring, which is faster, more convenient, and more productive. The entire RCS cylinder range is rated for high-pressure; 10,000 psi (700 bar).
10-tonne, 38mm stroke Enerpac RCS101 Low Height Hydraulic Cylinder
| Model | Capacity | Stroke | Collapsed Height | Extended Height | Operating Pressure | Return Type | Return type | Oil Capacity Advance | Coupler | Weight |
| RCS101 | 10 Tonne | 38 mm | 88 mm | 126 mm | 700 Bar | Single Acting | Spring Return | 55 cm3 | CR400 Coupler | 2.7 Kg |
The Full range of The ENERPAC RCS Low Height Hydraulic Cylinders - Available with different closed heights and different stroke lengths - Choose from below
| Model | Capacity | Stroke | Collapsed Height | Extended Height | Operating Pressure | Return Type | Return Type | Oil Capacity Advance | Coupler | Weight |
| RCS101 | 10 Tonne | 38 mm | 88 mm | 126 mm | 700 Bar | Single Acting | Spring Return | 55 cm3 | CR400 Coupler | 2.7 Kg |
| RCS201 | 20 Tonne | 45 mm | 98 mm | 143 mm | 700 Bar | Single Acting | Spring Return | 129 cm3 | CR400 Coupler | 5.0 Kg |
| RCS302 | 30 Tonne | 62 mm | 117 mm | 179 mm | 700 Bar | Single Acting | Spring Return | 261 cm3 | CR400 Coupler | 6.8 Kg |
| RCS502 | 50 Tonne | 60 mm | 122 mm | 182 mm | 700 Bar | Single Acting | Spring Return | 373 cm3 | CR400 Coupler | 10.0 Kg |
| RCS1002 | 100 Tonne | 57 mm | 141 mm | 198 mm | 700 Bar | Single Acting | Spring Return | 722 cm3 | CR400 Coupler | 20.7Kg |
What is frequently bought with the 10-tonne, 38mm stroke Enerpac RCS101 Low Height Hydraulic Cylinder
HC7206 High-Pressure Hydraulic Hose x 1.8m Long.
GA45GC 45° Angled Gauge Adaptor Assembly.
P39 Single Speed Steel Hydraulic Hand Pump.
Alternative pumps available
XC1202MB Cordless Hydraulic Pump.
XA12 Air-Driven Hydraulic Foot Pump.
PATG1102N Turbo II air Hydraulic Pump.
PUJ1201B Two-Speed Economy Electric Hydraulic Pump.
Key Features on the RCS Low Profile Hydraulic Cylinders
Lightweight, low-profile design for use in confined spaces.
Baked enamel finish for increased corrosion resistance.
Plunger wiper reduces contamination, extending cylinder life.
CR400 coupler and dust cap are included on all models.
Grooved plunger end with threaded holes for mounting tilt saddles.
Plated steel plungers.
Single-acting spring return.
RCS101, 101 kN Capacity, 38 mm Stroke, Low Height Hydraulic Cylinder (RCS101, 11.2 Ton Capacity, 1.5 in Stroke, Low Height Hydraulic Cylinder)
Model: RCS101
ECCN: EAR99
Harmonization: 8412210075
Series: RCS
Product Line: Industrial Tools
RCS-series, Low-Height Cylinders
Lightweight, low-profile design for use in confined spaces.
Single-acting, spring return.
Baked enamel finish for increased corrosion resistance.
Plunger wiper reduces contamination, extending cylinder life.
CR400 coupler and dust cap are included on all models.
Grooved plunger end with threaded holes for mounting tilt saddles.
Integral handle on RCS1002 for easy carrying.
Plated steel plungers.
| Model | Capacity | Stroke | Collapsed Height | Extended Height | Operating Pressure | Return Type | Return type | Oil Capacity Advance | Coupler | Weight |
| RCS101 | 10 Tonne | 38 mm | 88 mm | 126 mm | 700 Bar | Single Acting | Spring Return | 55 cm3 | CR400 Coupler | 2.7 Kg |
The Full range of The ENERPAC RCS Low Height Hydraulic Cylinders - Available with different closed heights and different stroke lengths - Choose from below
| Model | Capacity | Stroke | Collapsed Height | Extended Height | Operating Pressure | Return Type | Return Type | Oil Capacity Advance | Coupler | Weight |
| RCS101 | 10 Tonne | 38 mm | 88 mm | 126 mm | 700 Bar | Single Acting | Spring Return | 55 cm3 | CR400 Coupler | 2.7 Kg |
| RCS201 | 20 Tonne | 45 mm | 98 mm | 143 mm | 700 Bar | Single Acting | Spring Return | 129 cm3 | CR400 Coupler | 5.0 Kg |
| RCS302 | 30 Tonne | 62 mm | 117 mm | 179 mm | 700 Bar | Single Acting | Spring Return | 261 cm3 | CR400 Coupler | 6.8 Kg |
| RCS502 | 50 Tonne | 60 mm | 122 mm | 182 mm | 700 Bar | Single Acting | Spring Return | 373 cm3 | CR400 Coupler | 10.0 Kg |
| RCS1002 | 100 Tonne | 57 mm | 141 mm | 198 mm | 700 Bar | Single Acting | Spring Return | 722 cm3 | CR400 Coupler | 20.7Kg |
Why purchase equipment from Enerpac?
As a leading hydraulic tool innovator for 60+ years with several first-to-market products, Enerpac Solutions has lifted and moved some of the largest structures on earth. The latest advancements in quality, reliability, safety, and precision are what you will find in every Enerpac lifting tool from simple bottle jacks, cylinder, and hand pump sets to a wide selection of best-in-class cylinder and pump lifting systems. And when the load requires a unique lift from above or below, rely on synchronized, integrated heavy-lifting technologies designed for 1,000 tons or more.
