Electric Chain Hoists

Electric Chain Hoists For All Uses

We provide industrial chain hoists for use within the factory to be suspended from overhead beams, or electric hoists to be fitted to a jib crane. Ultimate Lifting can also offer electric chain hoists that can be used within the food industry and other wet environments.

Our team are able to offer electric chain hoists in standard 400 volt 3 phase supply, as well as 110 volt single phase electric chain hoists and 240 volt electric chain hoists. Most modern electric hoists can now be fitted with a radio remote control. Radio remote control electric hoists offer the operator more freedom to be positioned safely away from the danger area.

Explore Our Brands

Ultimate Lifting Solutions offers products from all the main brands, proudly stocking Yale Electric Chain hoists, Stahl electric Chain hoists, Liftket and GIS electric chain hoists. We can also provide electric chain hoists from all the leading manufacturers, including Lodestar Electric Hoists, Demag Hoists, Donati Hoists, Kito hoists and many others.

Electric Chain Hoists FAQ's

What are electric chain hoists?

Electric-powered chain hoists are ideal for raising or lowering loads without the operator needing to handle the item being lifted.

What can I use an electric hoist for?

Electric chain hoists are powered units that can lift, lower and move sideways any liftable load without the hoist operator needing to lift the bag himself. This thereby eliminates stress and strain on the body.

What are the different types of electric chain hoists?

The standard electric chain hoist is a hook suspension electric chain hoist. Electric chain hoists can also be supplied on a trolley to help move the load up or down a beam within the factory or on a construction site.

What capacity are electric chain hoists?

Electric chain hoists can be supplied in many different lifting capacities from as little as 125kgs to 20-tonne electric chain hoists. Here at ULS we stock a broad range of products spanning from small 125kg electric chain hoists to heavy load 20-tonne electric chain hoists, ensuring we have a product for your every need.

What voltage are electric chain hoists?

The most commonly supplied electric chain hoist is a 400-volt three-phase. However, 110-volt and 240-volt electric hoists are available.

What advantages are there to purchasing an electric chain hoist?

The main advantage of purchasing an electric chain hoist over a manual chain hoist is the speed of the lift; an electric hoist is faster to raise or lower than a manual chain hoist. Another advantage of the electric chain hoist is the operator will have little or no contact with the load - simply press a button on a pendant and the bag will move. In contrast, a manual chain hoist will require many effects to operate.

Choosing The Right Electric Chain Hoist

Ultimate Lifting Solutions understands how difficult it can be to choose the correct electric hoists.  ULS has been supplying electric chain hoists for over 40 years and we are here to help - consider the following criteria when selecting the right electric chain hoist. Alternatively, call ULS today at 01384 986 026 to discuss your requirements.

Capacity required - Max weight of the load to lift - 125Kgs, 250Kgs, 500Kgs, 1000Kgs, 1600Kgs, 2000Kgs, 2500Kgs, 3000Kgs, 5000Kgs. If you require a higher capacity, please contact our team.

The voltage of the hoist - Electric power supply - 400v 3ph 50Hz. 110v 1ph 50Hz 230v 1ph 50Hz.

Duty Rating - How often will the hoist be used - Light, Medium, Heavy.

Hoisting Speed - How fast the load will move - Single Speed, Dual Speed.

Falls of load chain - Single fall, two falls, no preference.

Suspension Type - What will hoist fit to - Hook, Lug, Push Trolley, Single Speed Electric Trolley, Dual Speed Electric Trolley

Height of Lift (HOL) - How high will the hoist be fitted - Standard 3m, 4m, 5m, 6m, 8m, 10m, 12m, 15m. If you require a higher height of lift, please call ULS.

Pendant Type - Standard wired-in pendant or radio remote control.

Pendant Length - Measured from the hoist - Standard length is 500m (0.5m), shorter than HOL. I.e. on a 3m HOL hoist, the pendant will be 2.5m.

Chain Container - Keeps excess chain tidy and out of the way - Yes, required, not needed.

Weatherproof cover/coat - Help protect against rain or water - Yes, required, not needed as indoor only.

Ambient Conditions - Where is the hoist used - normal conditions, high humidity or wet, dust environment, dirt environment. High temperature. If not ordinary, please call ULS to discuss.

The environment of use of electric chain hoist - Is your electric hoist to be used consistently outdoors? If so, you will need to consider the level of protection you require for your electric chain hoist when using it outside. The most straightforward protection to add to your hoist is a weatherproof cover, also known as a rain cover. Even with a rain cover, it is always sensible to invest in extra protection. A standard procedure is to add a roof over the parked position of the hoist, also known as a hoist dog kennel; this hoist house will keep the rain off the electric hoist when it is not in use. The best way to protect your electric hoist is to store it inside and only attach it to the jib or beam when it is ready to be used.

Power Supply of Hoist - You will need adequate power close to where the hoist is used. The best practice is to have a supply control panel and circuit breaker installed adjacent to the jib or overhead beam and jump a supply over to a locally mounted isolator.

Hoist Operation - How long is the hoist in operation at one time? How many are complete load cycles per hour? how many hours per day are in constant use? What is the distance covered per cycle?

Ask the experts - If you have any doubts or need assistance choosing the correct electric hoist. Please ask an Ultimate Lifting Solutions sales team member before purchasing online at www.ULSLIFTING.com.
