RUD VWBG Load Ring, Metric thread

Brand:

Capacity

6,000Kgs up to 40,000Kgs
(6t to 40t)
M33 to M100

Description

Rud VWBG Load Ring for bolting. 360° rotation with Ball bearing for shock free rotating & turning with less friction. Classed as the premier make of swivel lifting point. These are top quality. Suspension ring with enlarged pivoting area, plus many more design features.

£409.85 ex VAT

£491.82 inc VAT

Please note: We are able to supply & deliver the M33, M60 & M100 model (1500Ltrs/2000Kgs) on request.

Please call us on 01384 986 026 for pricing and availability.

Related products

RUD VWBG-V Load Ring, Metric thread

VWBG - V

Rud VWBG-V Load Ring for bolting. 360° rotation with Ball bearing for shock-free rotating & turning with less friction. Classed as the premier makes of the swivel lifting point. These are top quality. Suspension ring with an enlarged pivoting area, plus many more design features.

£77.19 ex VAT

£92.63 inc VAT

RUD VWBG-V Load Ring, Metric thread with longer Vario Bolt

VWBG - V Long

Rud VWBG-V (with longer Vario Bolt) Load Ring for bolting. 360° rotation with Ball bearing for shock-free rotating & turning with less friction. Classed as the premier makes of swivel lifting point. These are top quality. Suspension ring with the enlarged pivoting area, plus many more design features.

£98.48 ex VAT

£118.18 inc VAT

RUD VWBG Load Ring, Metric thread with longer Vario Bolt

VWBG Long

Rud VWBG Load Ring (with Longer Vario Bolt) for bolting. 360° rotation with Ball bearing for shock free rotating & turning with less friction. Classed as the premier make of swivel lifting point. These are top quality. Suspension ring with enlarged pivoting area, plus many more design features.
Rud VWBG Load Ring for bolting. 360° rotation with Ball bearing for shock free rotating & turning with less friction. Classed as the premier make of swivel lifting point. These are top quality. Suspension ring with enlarged pivoting area, plus many more design features

Comprehensive range of WLL 6 t / 50 t.

Clear marking of the minimum WLL for all loading/directions. Higher WLL possible when location and installation is optimized.

Rotatable at nominal WLL, 90° to the bolt-on direction.

Variable bolt lengths available for tapped or through holes.

VWBG-V: Non removable special bolt (this reduces the risk of improper standard bolts).

VWBG-V: RUD bolts with special corrosion protection Corrud-DT.

Large distance between bolt-on surface and load to avoid damage.

Model
Capacity
Thread
RUD Order Ref No
Weight
Thread Length
VWBG
6t
M33
8600150
5.6 Kgs
13mm
VWBG
8t
M36
7999059
4.7 Kgs
17mm
VWBG
12t
M42
7999044
6.1 Kgs
21mm
VWBG
12t
M45
7900455
6.24 Kgs
21mm
VWBG
13t
M48
7999045
6.37 Kgs
25mm
VWBG
14t
M52
7901081
10.55 Kgs
27mm
VWBG
16t
M56
7999004
10.68 Kgs
33mm
VWBG
16t
M60
8600454
11.37 Kgs33mm
VWBG
16t
M64
7999043
11.4 Kgs
40mm
VWBG
 31.5t
M72
7900097
29.96 Kgs
41mm
VWBG
35t
M80
7900100
31.19 Kgs
50mm
VWBG
40t
M90
7903408
34.5 Kgs
50mm
VWBG
40t
M100
8600458
36.5Kgs
50mm
Also available in Metric Fine Thread,  UNC and BSW-Whitworth imperial Threads.
Comprehensive range of WLL 6 t / 50 t.

Clear marking of the minimum WLL for all loading/directions. Higher WLL possible when location and installation is optimized.

Rotatable at nominal WLL, 90° to the bolt-on direction

Variable bolt lengths available for tapped or through holes.

VWBG-V: Non removable special bolt (this reduces the risk of improper standard bolts).

VWBG-V: RUD bolts with special corrosion protection Corrud-DT.

Large distance between bolt-on surface and load to avoid damage.

Model
Capacity
Thread
RUD Order Ref No
Weight
Thread Length
VWBG
6t
M33
8600150
5.6 Kgs
13mm
VWBG
8t
M33
7999059
4.7 Kgs
17mm
VWBG
12t
M42
7999044
6.1 Kgs
21mm
VWBG
12t
M45
7900455
6.24 Kgs
21mm
VWBG
13t
M48
7999045
6.37 Kgs
25mm
VWBG
14t
M52
7901081
10.55 Kgs
27mm
VWBG
16t
M56
7999004
10.68 Kgs
33mm
VWBG
16t
M60
8600454
11.37 Kgs33mm
VWBG
16t
M64
7999043
11.4 Kgs
40mm
VWBG
 31.5t
M72
7900097
29.96 Kgs
41mm
VWBG
35t
M80
7900100
31.19 Kgs
50mm
VWBG
40t
M90
7903408
34.5 Kgs
50mm
VWBG
40t
M100
8600458
36.5Kgs
50mm
Also available in Metric Fine Thread,  UNC and BSW-Whitworth imperial Threads.
In-service Inspection and Maintenance
Maintenance requirements are minimal. Keep eyebolts clean, protect from corrosion and protect threads from damage. Do not attempt to straighten bent eyebolts or re-cut threads.
Regularly inspect eyebolts and, in the event of the following defects, refer the eyebolt to a Competent Person for thorough examination: illegible markings; distortion; worn, or bent shanks and threads; incomplete or incorrectly formed threads; damaged eyes; nicks, gouges, cracks, corrosion or other defects.

In the UK, the Lifting Operations & Lifting Equipment Regulations (LOLER) make it clear that all shackles and eyebolts used for lifting purposes are lifting accessories. They should therefore be subject to a thorough examination by a competent person at least every six months. Regardless of the prevailing legislation, the Lifting Equipment Engineers Association (LEEA) strongly recommends that this policy is adopted by all those with responsibility for ensuring the safe condition of lifting equipment.
If you are in any double please contact Ultimate Lifting Solutions to discuss your LOLER / Thorough Examination requirements, we have trained engineers that can carry out all your inspection / services either on-site or in-house.
The RUD Group is a dynamic and modern family group, that is active worldwide. Our goal is continuous, profitable growth – with serious consideration for the careful treatment of our natural resources and our environment.

We are striving for a clear leadership position with our products and services in our market segments based on organisational and operational excellence.

With over 140 years of experience and, taking round steel chains as a basis, we develop future-oriented solution concepts with chain systems and components in diverse forms and for a wide range of applications.

We see our products as the result of our passion to creativity and perfection in our core competences metal working, welding, heat treatment, surface technology and forging.

Long-term partnership with our customers, their satisfaction and trust in us are the heart of everything we do. We vouch for customer-oriented, innovative, value-added technology as well as consistent top quality and safety. That is our joint responsibility.

Through our actively practiced, open and trusting corporate culture as well as our ongoing training and education, our international family enterprise is a motivated, energetic, flexible and competent team.

Our applied concept of Courtesy of Choice is reflecting the centuries-old philosophy that acknowledges differences while allowing them to exist together in harmony.
