Scaffold Runway System

The Scaffold Runway System from NIKO is a quality modular system that bolts directly onto standard scaffold tubing to create a safe lightweight crane system for lifting and lowering goods to the desired location. ULS Lifting supplies everything required including scaffold hanging brackets, track, joints, and an integral sliding trolley that most manual or electrical hoists can be fitted to quickly and easily to create a scaffold lifting beam. See the page download section for more information on how to install and use a Scaffolding Runway System.

Scaffolding Runway Kit includes:

Track - Supplied in 3m lengths.

Joints (where needed) - To connect the track.

Intermediate support hanging brackets (located in the centre of every track length and at either end of every system) - Connect the track to the scaffold tubes above.

Load Trolley with Clevis Pin (T48) to suspend a suitable hoist from - The standard load trolley does not have a rotating eye, a rotating eye can be used (T40), but the SWL is reduced.

End stops and ultimated stop cross bolts at either end of the system (Stops the trolley from falling out).

The Niko Scaffolding Runway System for hoists can be assembled to any scaffold structure and then fitted with a suitable manual or electric hoist, now creating a runway system for both lifting and transporting loads around any construction or building site - Any construction site worker can safely lift building materials to any level required without hard manual lifting or lower any waste away back down to the ground level.

Tested and certified runways in five different Capacities - SWL = 125Kgs, 250Kgs, 500Kgs, 1,000Kgs, and 1,600Kgs. Supplied in zinc-plated finish to protect against the elements and to help protect the system from rusting.

The Scaffold runways are supplied in kit form is easy and quick onsite installation - Scaffold runway kits are supplied with either 3m or 6m track lengths that connect together. Systems can be quickly and constantly refigured to suit site conditions - The kits are supplied with all parts required to create a lightweight yet robust runway system tested and certified to carry loads.

Key Features of the Scaffolding Runway System

Clamps to any existing scaffolding structure.

Lift and move loads up from 125 kg to 2000kg.

Cantilever over the end of the scaffolding.

Available in straight track and curved sections.

Change direction by adding a junction switch.

Suspend a bridge from 2 runways to create a crane system.

Supplied in kit form for ease of installation, extension, and relocation.

Some components approved EN795 for fall arrest.

Please contact ULS Lifting on 01384 986 026 if you require a specialist scaffold runway system, as we can supply track bends and 4-way junction sections if full movability is removed
