250Kgs SWL Column Mounted Jib Cranes - Under-Braced

Estimated lead time:Manufactured in UK to Order Approx. 3 - 4 Weeks Delivery

Please call us if you need this item sooner

CLICK
& COLLECT
Next day
delivery
SAME DAY
DELIVERY
(Call us)

Seen this product cheaper elsewhere?

We will always try to offer this product at the best price. We will do our best to not just match it but to beat it.

Price match
promise

250Kgs SWL Column Mounted Jib Cranes - Under-Braced

Brand:

Capacity

125Kgs

Description

250Kgs SWL Column Mounted Jib Cranes - Under-Braced. Manufactured in the UK. Designed purposely for low-height situations. Jib Arm can be manufactured to any length between 2m-6m and slew through 180° giving a very wide working area.

£998.98 ex VAT

£1,198.78 inc VAT

Please contact our sales team if the following extras are required:

1 - Adjustable Slew Limits
2 - Slewing Lock
3 - Installation

Related products

Festoon System for Overhead Cranes & Hoists

FEST SS

C Rail Style Festoon System  (Full Kit) including flat form power cable, cable trolleys & track. These simple-to-install lightweight kits provide a safe and economical means of supplying power to overhead hoists, overhead cranes, and most other types of moving machinery that travels along a fixed track. Once fitted eliminates dangerous dangling down cables and looks like a professional install or refit

£124.98 ex VAT

£149.98 inc VAT

250Kgs SWL Column Mounted Jib Cranes - Over Braced

CMJC

250Kgs SWL Column Mounted Jib Cranes - Over Braced versions are manufactured in the UK. These column Jib cranes are ideal if you are looking for a crane suspended securely from an existing column, pillar, or stanchion within your building. The two parts are connected using the supplied pivot pin. The arm can be manufactured to any length between 2m and 6m and the arm is designed to slew through 180° giving a very wide working area.

£594.98 ex VAT

£713.98 inc VAT

VSIII Yale Manual Hand Chain Hoist

VSIII

The Yale VS Chain hoist is a quality branded manual hand chain hoist, that combines all the features expected by the user - Quality, Safety and performance. SUITABLE for FLEETING as well as standing lifting operations.

£167.32 ex VAT

£114.98 ex VAT

£137.98 inc VAT

Stahl ST Electric Chain Hoist - 400volt output

ST

Stahl ST Electric Chain Hoist - 400volt output series from Stahl is an acknowledged top-level quality product that ranks amongst the world's most distinctive and extensive ranges of electric hoists on offer - A robust classic design/layout which proves itself in operation day for day. Powerful, reliable yet undemanding with power consumption and maintenance.

£1,388.98 ex VAT

£1,034.18 ex VAT

£1,241.02 inc VAT

ULS Lifting Solutions are pleased to offer our UK-manufactured and fully certified range of 250Kgs SWL Column Mounted Jib Cranes - Under-Braced versions that are Ideal solution for use within a factory or workshop that has structural steelwork, pillars, or stanchions. Manufacturing the clamp around Swing Jib from an I-Beam enables the strengthening to be engineered under the Jib Arm thus creating a more compact Jib that can be used in areas that may be restricted by height.

Another great selling point to the Under-Braced Swing Jib Arm enables the use of a powered trolley and Electric hoist to assist the movement along the beam, ideal if the Jib arm is being been overreaching a walkway or used over a tank or raised floor areas. The arm is designed to have either a manual or powered trolley, making it even more simple for connecting to your hoist, spring balancer, or vacuum lifter.

Supplied in a simple two-part kit form, the main slewing arm which the hoist will move along, and a pair of brackets that will clamp around the pillar or column. The two parts are connected using the supplied pivot pin. The arm can be manufactured to any length between 2m and 6m and the arm is designed to slew through 180° giving a very wide working area.

Please note - Anti-Slip measures must be taken to ensure the Jib Arm does not slip or move down the column once fitted. Ultimate Lifting Solutions can advise or can Install all types of Jib cranes and Jib Arms.

Dimensions for Column Mounted under-braced Jib Cranes (for illustration only)
ModelSWLArm Length (R) Radius of reach
Bracket WidthArm Height (B)Total Weight
UBCMJC250R2
250Kgs
2,000mm (2m)
380mm
500mm95Kg
UBCMJC250R3
250Kgs
3,000mm (3m)
380mm
750mm101Kgs
UBCMJC250R4
250Kgs
4,000mm (4m)
380mm
800mm
129Kgs
UBCMJC250R5
250Kgs
5,000mm (5m)
380mm
900mm190Kgs
UBCMJC250R6250Kgs
6,000mm (6m)
380mm
1,000mm
200Kgs
All Under-Braced Column Mounted Jib Cranes supplied by Ultimate Lifting Solutions Limited are supplied with Duty Classification A3 according to BS733: 1990
All Column Mounted Jib Cranes - Under Braced design supplied by Ultimate Lifting Solutions Limited are supplied fully tested & Certified.
The paint Finish is a high-quality Yellow Powder Coat to RAL1004 - other colours available on request.
Galvanised Column Mounted Jib Arms and Stainless Steel Column Mounted Jib Arms are available on request.

Why Choose a 250Kgs SWL Column Mounted Jib Cranes - Under-Braced?
There are many advantages to purchasing a clamp around Under-Braced Jib Crane, they are extremely versatile within the factory, speeding uplifting, moving components off presses or workbenches, and loading or unloading lorries. Lifting heavy objects such as granite, timber, or steel. Manufactured with an I-Beam enable this style of swing Jib arm to be used with either push travel or motorized traveling trolley
Column Jib cranes are made up of two main parts, the arm and set of brackets to attach to existing steelwork, therefore these simple manual jib cranes do not have many parts to maintain, making them extremely reliable, which in turn means they do not break down, so no loss in production time.

Easy to install
The column-mounted swing crane that has Under Bracing simply just bolt to existing columns, pillars, stanchions, or any suitable structural steelwork, once you have checked your column is suitable for a jib crane, choose which one you require from the drop-down menus, we will arrange to manufacture the jib and dispatch it direct to site for your required delivery date. Then, when it is supplied to the site, The Jib just needs to be secured to the steelwork (Anti-slip measures must be taken to ensure that the jib crane can’t slip down the support column) -  We at Ultimate Lifting Solutions offer this service and can offer full installation by using our own highly trained engineers or just the commissioning/ load testing, we can offer a package to meet your requirements.

Because of the simple design, they are inexpensive to both buy and maintain compared to other cranes. Under normal working conditions, they will only need an industry standard 12 monthly service. We at Ultimate Lifting Solutions offer this service and can offer various maintenance/service packages to meet your requirements.

How does Clamp Around Under-Braced Swing Jib Arm work?
A standard column mountable swing Jib Arm Low Height version has two main parts - The Arm and mounting brackets. The arm can rotate from left to right and vice versa, the swing or slew angle is set at 180° as standard. On all our I-Beam style swing jib arms up to 250Kgs, they will slew with ease without the requirements of powered assistance, hence keeping the costs down.
The arm on our Jib cranes has been designed to be used with either a Electric Travel Trolley or Push Travel Trolley, this moves along the full length of the arm, the trolley gives you the freedom and flexibility to reach into corners of your factory with ease.

What else is required for 250Kgs SWL Column Mounted Jib Cranes - Under-Braced
You now have your Swing Jib fitted. You now need a hoist of some type or a vacuum lifter, Lifting Chains, or a spring/tool balancer, these fit easily to the Jib crane via a traveling trolley.  You just need to decide what hoist you need. To keep the costs down a manual hoist is the cheapest option, but you will not save on production time, as they are slow and do need assistance by hand, and sometimes for larger items, you might not be able to reach the hoist chain. The second option and best option is an Electric Hoist, these hoists enable you to easily lift and lower your components quickly, cutting down on production time, and it will soon pay for itself in time saved.

Installation of 250Kgs SWL Column Mounted Jib Cranes - Under-Braced Version.
As mentioned above, the Swing Jib Arm can be an easy install, once installed and the hoist fitted, all that is left is commissioning, testing, and signing off the Jib as safe to use. we are more than happy for all our customers to install themselves using the instructions supplied or find their own installation team. But, these days time is precious, do you have time to sort engineers and dates, etc, Let us save you time as we are also more than happy to offer our own engineers to take away this task. We can install the Jib, install the Hoist, commission, and test and we will not leave the site until everything is working correctly and safely.

Ask the Experts about 250Kgs SWL Column Mounted Jib Cranes - Under-Braced versions.
Ultimate Lifting Solutions, with over 40 years experience within both the crane industry and lifting gear industry are happy to assist with any questions with regards to Jib cranes and lifting gear. We want our customers to choose the correct kit for the correct job and the best price. So we are always available to answer questions and help design bespoke crane systems or discuss the lifting gear to hang off the crane or discuss the installation of the Jib Crane. Contact the Ultimate Lifting Solutions team today by telephone at 01384 986 026 or by email at sales@ulslifting.com

250Kgs SWL Column Mounted Jib Cranes - Under-Braced


All our manufactured Under-Braced Column Mounted Jib Cranes are

Duty classification:  A3 according to BS 733: 1990

All jibs are lubrication free. The pivot bushes are acetal and therefore do not require lubrication.

Manual slewing operation.

Minimal maintenance requirement.

Clutch controlled slewing mechanism, can be tightened/loosened to control how freely the arm pivots.

Bases are fully welded to the column – in most situations, this removes the need for an oversized load spreading plate or setting an anchor frame into concrete, therefore making installation much quicker and more cost-effective.


Key Points of our UK-manufactured Jib Cranes

SWL - 250kg.

Arm length - 2m up to 6m.

Slew Angle - 180-degree manual slew.

Trolley - Can be Fitted with a push travel trolley or powered trolley for suspending hoists, vacuum lifters, and tool balancers from.

Fast delivery - We aim to deliver all our Swing Jibs within 2 to 3 weeks


Optional extras

Adjustable slewing limits, To reduce the swing arc

Slewing lock, to fix the arm into a specific position

Electrical Isolator - required if the electric hoist is to be used in conjunction with the Jib Arm



Full Electric Kit - Our kit includes everything required to fun Electric Hoist (Isolator, Flatform Supply Cable, Cable Runners)


Kit can be supplied to enable the pin to be fitted from below.

250Kgs SWL Column Mounted Jib Cranes - Under-Braced style as a rule do not need much service or maintenance. Yet, general observations of the overall condition of the jib and the hoist connected to it can be carried out by the operator - any faults should be reported immediately


More importantly to keep the Jib and hoists running at maximum efficiency and to keep within the UK laws regarding LOLER inspections set out by HSE, both the Jib and the hoist on it should have a maintenance service scheduled no later than 12 months. This service should be undertaken by qualified service engineers - If you would like to know more about the servicing and general maintenance, please feel free to contact us, we do have qualified engineers and are happy to quote for all your crane servicing requirements.
