250Kgs SWL Wall Mounted Jib Crane Galvanised Finish for Outdoor Usage

Key notes for ordering:

Dispatched as a kit with instructions, decide on extras like isolator for electrics, festoon system for elec hoist. Contact us for installation prices. Suppled with certification.

Estimated lead time:Manufactured in UK to Order Approx. 3 - 4 Weeks Delivery

Please call us if you need this item sooner

CLICK
& COLLECT
Next day
delivery
SAME DAY
DELIVERY
(Call us)

Seen this product cheaper elsewhere?

We will always try to offer this product at the best price. We will do our best to not just match it but to beat it.

Price match
promise

250Kgs SWL Wall Mounted Jib Crane Galvanised Finish for Outdoor Usage

Brand:

Capacity

250Kgs

Description

All our Galvanised Wall / Face Fixed Fixed Jib Cranes are manufactured in the UK. The ULS Hot Dipped Galvanised Jib Crane is idea for both outdoor or indoor locations that will be subjected to any type of moisture, widely used in applications where corrosion resistance is needed and are more cost effective than our stainless steel version.

£1,044.55 ex VAT

£1,253.46 inc VAT

Please contact our sales team if the following extras are required:

1 - Adjustable Slew Limits
2 - Slewing Lock
3 - Installation
Add to cart Add to quote

Related products

Festoon System for Overhead Cranes & Hoists

FEST SS

C Rail Style Festoon System  (Full Kit) including flat form power cable, cable trolleys & track. These simple-to-install lightweight kits provide a safe and economical means of supplying power to overhead hoists, overhead cranes, and most other types of moving machinery that travels along a fixed track. Once fitted eliminates dangerous dangling down cables and looks like a professional install or refit

£178.88 ex VAT

£214.66 inc VAT

250Kgs SWL Wall Mounted Jib Cranes

WMJC

All our Wall or Face fixed Jib Cranes are manufactured in the UK. These Wall Mounted Jib cranes are ideal if you are looking for a Jib Crane that can be bolted or welded securely to an existing wall, pillar, column or stanchion within your building.

£492.63 ex VAT

£591.16 inc VAT

VSIII Yale Manual Hand Chain Hoist

VSIII

The Yale VS Chain hoist is a quality branded manual hand chain hoist, that combines all the features expected by the user - Quality, Safety and performance. SUITABLE for FLEETING as well as standing lifting operations.

£167.32 ex VAT

£114.98 ex VAT

£137.98 inc VAT

CM Lodestar Electric Chain Hoists (110V)

CM Lodestar 110v

The 110-volt LODESTAR Electric Chain Hoist. Is a top-specification tough & durable hoist, known for its heavy-duty never stop working always reputation. Designed to keep working in the most arduous applications and is a recognised and proven hoist within the hire industry as the number one supplied kit where high duty, combined with long heights of lifts are required

£1,969.88 ex VAT

£2,363.86 inc VAT

250Kgs SWL Column Mounted Jib Crane Galvanised Finish for Outdoor Usage

CMJC-GALV

All our Galvanised Column Mounted Jib Cranes are manufactured in the UK. The ULS Hot Dipped Galvanised Jib Cranes are idea for both outdoor or indoor locations that will be subjected to any type of moisture, widely used in applications where corrosion resistance is needed and are more cost effective than our stainless steel version.

£1,069.94 ex VAT

£1,283.93 inc VAT

All our Galvanised Wall or Face fixed fixed Jib Cranes are manufactured in the UK.

The ULS Hot Dipped Galvanised Jib Cranes are idea for both outdoor or indoor locations that will be subjected to any type of moisture, widely used in applications where corrosion resistance is needed and the galvanised version Jib is more cost effective than our stainless steel version. Our galvanised Jib Cranes are commonly used in any outdoor location such as quarries, mariners, harbours, river/coastal locations and utility or water treatment plants. Indoor locations can be anywhere that has humid conditions such as plant rooms or pump rooms.

These Wall Mounted Jib cranes are idea if you are looking for a Jib Crane that can be bolted or welded securely to an existing wall, pillar, column or stanchion within your building. Supplied as a simple two part kit form, the main slewing arm which the hoist will move along, and a pair of brackets that will welded or bolted to the wall/column. The two parts are connected using the supplied pivot pin. The arm can be manufactured to any length between 2m and 6m and the arm is designed to rotate giving a very wide working area. The arm has a trolley already fitted, making it even more simple for connecting to your hoist, spring balancer or vacuum lifter.

Dimensions for illustration only
Model
SWL
Overall Height Of Arm
Trolley Depth
Arm Length (Radius of reach)
Total Weight
WMJC250R2
250Kgs
500mm
77mm
2,000mm (2m)
50Kgs
WMJC250R3
250Kgs
750mm
77mm
3,000mm (3m)
52Kgs
WMJC250R4
250Kgs
800mm
77mm
4,000mm (4m)
71Kgs
WMJC250R5
250Kgs
900mm
94mm
5,000mm (5m)
105Kgs
WMJC250R6
250Kgs
1000mm
94mm
6,000mm (6m)
124Kgs

Why Choose a Wall or Face Fixed Mounted Jib Crane?
There are many advantages in purchasing a Wall Mounted Jib Crane, they are extremely versatile within the factory, speeding up lifting and moving components off presses or work benches, loading or unloading lorries. Lifting heavy objects such as granite, timber or steel.

Wall Jib cranes are made up of two main parts, the arm and set of brackets to attach to existing steelwork, therefore these simple manual jib crane do not have many parts to maintain, making them extremely reliable, which in turn means they do not break down, so no loss in production time.

Why Choose a Hot Dipped Galvanised?
The simple answer is that by galvanising the the jib crane it will prevent premature rust and corrosion to the jib, which means they are perfect for any location that could be subjected to either atmospheric conditions or wet / humid conditions.

Easy to install
These wall mounted cranes simply just bolt to existing walls, columns, pillars, stanchions or any suitable structural steelwork, once you have checked your column is suitable for a jib crane, choose which one you require from the drop down menus, we will arrange to manufacture the jib and dispatch it direct to site for your required delivery date. Then, when it is supplied to site, The Jib just needs to be secured to the wall or steelwork -  We at Ultimate Lifting Solutions offer this service, and can offer full installation by using our own highly trained engineers or just the commissioning/ load testing, we can offer a package to meet your requirements.

Because of the simple design they are inexpensive to both buy and maintain compared to other cranes. under normal working conditions, the Jib itself will only need an  industry standard 12 monthly service. We at Ultimate Lifting Solutions offer this service and can offer various maintenance / service packages to meet your requirements.

How do Swing Jib Crane work?
A standard swing Jib as mentioned has two main parts - The Arm and mounting brackets. The arm can rotate from left to right and vice versa, the swing or slew angle is set for wall mounted at 180° as standard. On all our swing jibs up to 1,000Kgs they will slew with ease without the requirements of powered assistance, hence keeping the costs down.
The arm on our Jib cranes will be supplied with a integral push travel trolley, this moves along the full length of the arm, the trolley gives you the freedom and flexibility to reach into corners of your factory with ease.

What else is required for Wall Mounted Jib Crane?
You now have your Swing Jib fitted. You now need a hoist of some type or a vacuum lifter or a spring / tool balancer, these fit easily to the trolley that was supplied already fitted within the jib crane arm.  You just need to decide what hoist do you need. To keep the costs down a manual hoist is the cheapest option, but you will not save on production time, as they are slow and do need the assistance by hand, and sometimes for larger items, you might not be able to reach the hoist chain. The second option and best option is an Electric Hoist, these hoists enable you to easily lift and lower your components quickly, cutting down on production time, it will soon pay for itself in time saved.

Installation
As mentioned above, the Wall or Face Mounted Jib Crane can be an easy install, once installed and the hoist fitted, all that is left is commissioning, testing and signing off the Jib as safe to use. we are more than happy for all our customers to install themselves using the instructions supplied or find their own installation team. But, these days time is precious , do you have time to sort engineers and dates etc, Let us save you time as we are also more than happy to offer our own engineers to take away this task. We can install the Jib, install the Hoist, commission, test and we will not leave site until everything is working correctly and safely.

All our manufactured Jibs are

Duty classification:  A3 according to BS 733 : 1990

All jibs are lubrication free.  The pivot bushes are acetal and therefore do not require lubrication. The trolleys running surfaces are also lubrication free.

Manual slewing and trolley travel operation

Minimal maintenance requirement

Clutch controlled slewing mechanism, can be tightened/loosened to control how freely the arm pivots.

Bases are fully welded to the column – in most situations this removes the need for an oversized load spreading plate or setting an anchor frame into concrete, and therefore making installation much quicker and more cost effective.


Key Points of our UK manufactured Jib Cranes

SWL - 250kgs

Arm length - 2m up to 6m

Slew Angle - Wall mounted, Max 180° Manual Slew

Trolley - Fitted with integrated push travel trolley for suspending hoists, vacuum lifters and tool balancers from

Fast delivery - We aim to delivery all our Swing Jibs within 10 to 14 days


Optional extras

Adjustable slewing limits, To reduce the swing arc

Slewing lock, to fix the arm in to a specific position

Electrical Isolator - required if electric hoist to be used in conjunction with the Jib Arm


Full Electric Kit - Our kit includes everything required to fun Electric Hoist (Isolator, Flatform Supply Cable, Cable Runners)


Optional Floor Fixing Bolts

Kit can be supplied to enable the pin to be fitted from below.

Jib Cranes as a rule do not need much service or maintenance. Yet, general observations of the overall condition of the jib and the hoist connected to it can be carried out by the operator - any faults should be reported immediately


More importantly to keep the Jib and hoists running at maximum efficiency and to keep within the UK laws with regarding LOLER inspections set out by HSE, both the Jib and the hoist on it should have a maintenance service scheduled no later than 12 months. This service should be undertaken by qualified service engineers - If you would like to know more about the servicing and general maintenance, please feel free to contact us, we do have qualified engineers and are happy to quote for all your crane servicing requirements.
